Sturdy And Compact Middle Size Raise Boring Rig Raise Hole From 2-3.5m (6-11ft)

Sturdy And Compact Middle Size Raise Boring Rig Raise Hole From 2-3.5m (6-11ft)
Sturdy And Compact Middle Size Raise Boring Rig Raise Hole From 2-3.5m (6-11ft) Sturdy And Compact Middle Size Raise Boring Rig Raise Hole From 2-3.5m (6-11ft) Sturdy And Compact Middle Size Raise Boring Rig Raise Hole From 2-3.5m (6-11ft)

Large Image :  Sturdy And Compact Middle Size Raise Boring Rig Raise Hole From 2-3.5m (6-11ft)

Product Details:
Place of Origin: China
Brand Name: Sinotechdrill
Certification: CE & ISO
Model Number: STD-R120D,STD-R80D,STD-R120VD
Payment & Shipping Terms:
Minimum Order Quantity: One set
Price: Negotiation
Packaging Details: Nude packing and wooden case available.
Delivery Time: 120 days after receiving deposit.
Payment Terms: L/C,T/T
Supply Ability: 10 PCS per month
Detailed Product Description
Nominol Raise Diameter: 3000mm Max Raise Diameter: 3500mm
2nd Raise Diameter: 4500mm Drill Angel Horizontal: 60-90
Pilot Hole: 282mm Max Torque: 197 KNm
High Light:

raise boring drilling

,

raise boring rig

3.5m raise diameter with 400m depth raiseboring equipment

Sinotechdrill STD-R RBM is medium-sized raise boring machine drill holes from 1.5 to 3.5 m in diameter. Standard functions include anti-jamming, full mechanized makeup and break out of drill pipes,Radio RCS(Rig control system),two drilling method and three operation models,high pressure load sensing hydraulic system and four poster two cylinder lower structure . We strive to construct high-quality raise machines that are easy to set up, operate and maintain – and our STD-R rigs are no exception. STD-R raise machines are built to serve and built to last.



FOUR-POSTER TOW-CYLINDER LOWER PROFILE

The STD-R series raise boring machines adopted an international mainstream pillar structure. It features reliable operation, fast mounting and dismounting, convenient maintenance , and small working space .

HIGH PRESSURE LOAD SENSING HYDRAULIC SYSTEM

The STD-R series raise boring machine hydraulic system with 40 Mpa high pressure has a number of advanced technologies such as constant power control, load - sensing control, multiple filtering proportional solenoid control and so on. In addition, the system stays ahead in mine field. The advanced advantages of higher intelligent degree, bigger power density, stronger anti–dirty ability and higher reliability can ensure that RBM effectively excavate for hard rock.

PATENTED TECHNOLOGY AND HIGH - LEVEL CONFIGURATION

Our large number of patented technology and numbers of international well-known components (such as electric parts hydraulic parts, transmission parts) are included in the RBM

Compared with same kinds of products, ours are more reliable and more durable



TWO DRILUNG MODES AND THREE OPERATION MODES

The control system supports two drilling modes (high accuracy drilling mode an speed drilling mode) and three operation modes (manual operation, wireless operation and wired operation). The user can select drilling mode according to accuracy requirement and geological conditions and select operation mode according to operating position and the actual situation.



FULL- MECHANIZED CONNECTING & BREAK NG OUT DRILL PIPES SYSTEM

By means of the automatic positioning technology and two hydraulic wrenches inserted dynamically, the operation that operators connect and break out drill pipes can be accomplished without being directed. The system greatly reduces working strength and saves auxiliary working time.



RCS INTELLIGENT CONTROL SYSTEM

The STD-R series raise boring machine installs RCS intelligent control system with safety protection automatic operation, fault diagnose, data storage, internet communications, digital display so on ( see specification of RCS intelligent control system )

Sturdy And Compact Middle Size Raise Boring Rig Raise Hole From 2-3.5m (6-11ft) 0

Sturdy And Compact Middle Size Raise Boring Rig Raise Hole From 2-3.5m (6-11ft) 1







Details Pictures

Sturdy And Compact Middle Size Raise Boring Rig Raise Hole From 2-3.5m (6-11ft) 2
