Product Details:
Payment & Shipping Terms:
|
| Depth: | 200 Meters | Dia.: | BTW 60mm |
|---|---|---|---|
| Hydraulic Pressure: | 21Mpa | Cooler: | Water Cold |
| High Light: | drilling rig equipment,atlas copco drill rigs,Geological Exploration Core Drill Rig |
||
P200G Type Man Portable Drill Rig
Application
P200G portable full-hydraulic drilling rig is specially designed for engineering geological survey in inaccessible areas and those with complex topographical conditions, especially applicable for geological survey of railway, road and hydropower projects in such areas and for various other projects requiring high portability and efficiency of drilling rigs and subject to various construction requirements.It is the ideal drilling rig when operating in hard-to-access areas within a depth of 200 meters, executing small projects, conducting initial investigations and working on tight schedules.
Parameter
| Drill depth capacity |
HQ/NTW/BTW Rod length 1m (HQ/NTW/BTW) |
30/100/200m |
| Hole Diameter | 96/75.7/60mm | |
| Core Diameter | 63.5/56/42mm | |
| Engine power | Japan KUBOTA 23.5kw/3000rpm | |
| Hydraulic system | Maximum pressure 21Mpa/max Maximum flow 54L/min Water cooled | |
Top drive rotation head
| Maximum toque | 400NM |
| Maximum rotation speed | 1300rpm |
| Feed travel (Cylinder drive) | 1.27m |
| Pull/thrust | 33KN/24KN |
Winch
| Average speed | 150m/min |
| Lift | 600kg |
| Were Diameter/Accommodation | 5mm/240m |
Mast
| 5m；Height | |
| Drill Angle | 45°-90° |
Size and weight
| Platform area/Module quantity | 3m X 3m / 4PCS |
| Heaviest module/Gross | 176kg /513kg |
Highlights
1. Equipped with a new hexagonal guide rail system, it enjoys better strength, better orientation, adjustable abrasion-resistant plate and convenient maintenance.
2. More than 90% structural parts of the compete machine is made of high-strength airworthy light aluminum, ensuring lower weight;
3. It is equipped with a long-stroke feeding oil cylinder to ensure more convenient control than chain drive;
4. A motor can be used for power supply as needed.
