200m Lightweight Portable Drilling Rig Equipment With Kubota 23.5kw Engine

large.img.alt
small.img.alt small.img.alt small.img.alt

Large Image :  200m Lightweight Portable Drilling Rig Equipment With Kubota 23.5kw Engine

Product Details:
Place of Origin: China
Brand Name: Sinotechdrill
Certification: CCC,ISO
Model Number: P200
Payment & Shipping Terms:
Minimum Order Quantity: One unit
Price: Negotiation
Packaging Details: Nude and waxed
Delivery Time: Within 25 days after receiving deposit
Payment Terms: L/C, T/T
Supply Ability: 15 units per month
Detailed Product Description
Depth: 200m Dia.: 60mm
Engine: Kubota 23.5Kw Core Dia.: Water Cold
High Light:

drilling rig equipment

,

underground drilling equipment

,

23.5kw Engine Portable Drilling Rig

P200G Crawler Type Man Portable Drill Rig



Application

P200 can be used for drilling boreholes within 200m in depth, filling the gap of portable full-hydraulic drilling rigs. Featuring light weight and high efficiency with a design inclination of 45-90 degree, it is a good exploration for shallow sampling.

P200 is widely used in mineral exploration, infrastructure construction (i.e. railway, road and bridge, etc.), hydraulic and hydropower project, tunnel exploration and geographical investigation. It works particularly well in areas with complex geographic characteristics such as mountainous regions, forests and plateaus

200m Lightweight Portable Drilling Rig Equipment With Kubota 23.5kw Engine 0

Parameter

Dill depth capacity HQ/NTE/TW 30/100/200m
Rod length 1.5m
Hole Diameter (HQ/NTE/TW) 96/75.7/60mm
Core Diameter Angel 45°-90° 63.5/56/42mm
Engine power KUBOTA 23.5kw/3000rm
Top drive rotation head Maximum torque/rotation speed 400NM/1300rpm
Feed travel/Pull/Thrust 1.27,33KN/24KN

200m Lightweight Portable Drilling Rig Equipment With Kubota 23.5kw Engine 1

Highlights

1. Equipped with a new hexagonal guide rail system, it enjoys better strength, better orientation, adjustable abrasion-resistant plate and convenient maintenance.

2. More than 90% structural parts of the compete machine is made of high-strength airworthy light aluminum, ensuring lower weight;

3. It is equipped with a long-stroke feeding oil cylinder to ensure more convenient control than chain drive;

4. A motor can be used for power supply as needed.

200m Lightweight Portable Drilling Rig Equipment With Kubota 23.5kw Engine 2
