Middle depth three meters raise boring machine 92kw diesel engine

small.img.alt small.img.alt small.img.alt small.img.alt

Large Image :  Middle depth three meters raise boring machine 92kw diesel engine

Product Details:
Place of Origin: China
Brand Name: Sinotechdrill
Certification: CE & ISO
Model Number: STD-R120
Payment & Shipping Terms:
Minimum Order Quantity: One set
Price: Negotiation
Packaging Details: Nude packing
Delivery Time: 120 days after receiving deposit.
Payment Terms: L/C,T/T
Supply Ability: 20 PCS per month
Detailed Product Description
Product Name: Riase Boring Feed Force: 2900KN
Lifting Force: 4300Kn
High Light:

horizontal directional drilling rig


directional drilling equipment

Middle depth three meters raise boring machine 92kw diesel engine

Sinotechdrill STD-R RBM is medium-sized raise boring machine drill holes from 1.5 to 3.5 m in diameter. Standard functions include anti-jamming, full mechanized makeup and break out of drill pipes,Radio RCS(Rig control system),two drilling method and three operation models,high pressure load sensing hydraulic system and four poster two cylinder lower structure . We strive to construct high-quality raise machines that are easy to set up, operate and maintain – and our STD-R rigs are no exception. STD-R raise machines are built to serve and built to last.

Middle depth three meters raise boring machine 92kw diesel engine 0


The control system supports two drilling modes (high accuracy drilling mode an speed drilling mode) and three operation modes (manual operation, wireless operation and wired operation). The user can select drilling mode according to accuracy requirement and geological conditions and select operation mode according to operating position and the actual situation.


By means of the automatic positioning technology and two hydraulic wrenches inserted dynamically, the operation that operators connect and break out drill pipes can be accomplished without being directed. The system greatly reduces working strength and saves auxiliary working time.


The STD-R series raise boring machine installs RCS intelligent control system with safety protection automatic operation, fault diagnose, data storage, internet communications, digital display so on ( see specification of RCS intelligent control system )

Middle depth three meters raise boring machine 92kw diesel engine 1


Unit STD-R40 STD-R80 STD-R120
Nominol raise diameter MM 1000 2000 3000
Max raise diamater MM 1500 2500 3500
Max raise depth M 200 300 500
Pilot hole MM 221 241 282
Drill angel horizontal ° 60-90 60-90 60-90
Feed force KN 1980 1980 2100
Lifting force KN 1980 1980 2100
Feed velocity M/min 5.6 7.7 7.0
Feed distance MM 1440 1440 1455
Clockwise torque kN.m 68 110 197
Anticlockwise torque kN.m 68 110 197
Rotation velocity R/min 0-24 0-24 0-24
Voltage V 380 380 380
Motor power KW 90 132 132
Motor rotation speed R/min 1480 1480 1480
