PQ HQ NQ BQ Wireline Impregnate Diamond Core Drill Bit With High Recovery Ratio

PQ HQ NQ BQ Wireline Impregnate Diamond Core Drill Bit With High Recovery Ratio
PQ HQ NQ BQ Wireline Impregnate Diamond Core Drill Bit With High Recovery Ratio PQ HQ NQ BQ Wireline Impregnate Diamond Core Drill Bit With High Recovery Ratio PQ HQ NQ BQ Wireline Impregnate Diamond Core Drill Bit With High Recovery Ratio PQ HQ NQ BQ Wireline Impregnate Diamond Core Drill Bit With High Recovery Ratio

Large Image :  PQ HQ NQ BQ Wireline Impregnate Diamond Core Drill Bit With High Recovery Ratio

Product Details:
Place of Origin: China
Brand Name: Sinotechdrill
Certification: CE & ISO
Model Number: A, B, N, H and P
Payment & Shipping Terms:
Minimum Order Quantity: 1 Pc
Price: Based on Detailed Order
Packaging Details: Standard carton box
Delivery Time: Based on Detailed Order
Payment Terms: T/T
Supply Ability: Based on Detailed Order
Detailed Product Description
Wireline Core Bit Size: A, B, N, H And P Type: Impregnated And Surface Set
Core Bit Crown Height: 8mm, 12mm, 16mm, 25mm Diamond Core Bit Waterway: CF, ECF, W, V, TB, And FD
Processing Type: Forging Core Bit Series: "Q" Series And "TW" Series
High Light:

core cutting drill bits

,

core bore drill bits

PQ HQ NQ BQ Wireline Impregnate Diamond Core Drill Bit With High Recovery Ratio



Wireline impregnated diamond coe bits
1. Available in all standard drilling sizes (A, B, N, H and P).
2. Various crown height and waterways design
3. Long lifespan and optimum penetration rate.
4. “Q” series and “TW” (Thin Wall) series

Reliable material and advanced technology
Sinotechdrill provide high standard diamond products, with a perfect match of top-tier raw material, advanced technology and local manufacturing resources. This enables Sinotecdrill to provide global customers with high-quality products at reasonable price.


Superior performance
The wireline core bits cutting ability has been developed to allow high penetration rate or low weight on bit when formation demands it. The exceptional durability and superior abrasion resistance have proven to increase drilling performance for a broad range of applications.



Threads:

Standard Q threads as well as thread types required by clients are available.


Size Available as followings:
"Q" series: AQ, BQ, NQ, HQ, PQ/AQTK, BQTK, BQ3, NQ2, NQ3, NQTT, HQ3, HQTT, PQ3, PQTT
T2 series: T2 46, T2 56, T2 66, T2 76, T2 86, T2 101
T6 series: T6 76, T6 86, T6 101, T6 116, T6 131

T series: T36, T46, T56, T66, T76, T86

Non-standard also can be made as your demand



Our Services

We will response in 8 hours to the problems caused by our products. When necessity arises inside the country, technical support will arrive in 24 hours within a 1000 kilometers radius of the company, will arrive in 48 hours for other parts of China. Due to the limitation of branch offices in foreign countries, technical support will arrive your work site in 15 days after visa is issued.



DIAMONDCORE BITS REAMING SHELLS
Size Bit-set OD/Hole Diameter Bit-set ID/Core Diameter
  mm inch mm inch mm inch
AQ 47.6 1.874 27 1.063 48 1.889
BQ 59.5 2.342 36.4 1.433 59.9 2.358
NQ 75.3 2.964 47.6 1.874 75.7 2.98
HQ 95.5 3.76 64.3 2.531 96.08 3.783
PQ 122 4.803 85 3.346 122.6 4.827
BQ3 59.5 2.342 33.5 1.32 59.9 2.358
NQ3 75.3 2.964 45 1.772 75.7 2.98
HQ3 95.5 3.76 61.1 2.406 96.08 3.783
PQ3 122 4.803 83.1 3.271 122.5 4.823



PQ HQ NQ BQ Wireline Impregnate Diamond Core Drill Bit With High Recovery Ratio 0



PQ HQ NQ BQ Wireline Impregnate Diamond Core Drill Bit With High Recovery Ratio 1

Our factory:
PQ HQ NQ BQ Wireline Impregnate Diamond Core Drill Bit With High Recovery Ratio 2

Packing & delivery:
PQ HQ NQ BQ Wireline Impregnate Diamond Core Drill Bit With High Recovery Ratio 3
PQ HQ NQ BQ Wireline Impregnate Diamond Core Drill Bit With High Recovery Ratio 4

FAQ

Q: What's your delivery time?
A: Commonly produce need 20 days to produce. Within 3 days if in stock.
Q: What methods of payment are accepted?
A: We agree T/T, L/C, West Union, One touch, Money Gram
Q: What about the shipment?
A: Based on order quantity and the length of drill rods. We can send it to you by Express, by Air, by Sea, and by Train. Or send the goods to your chinese agent.
Q: How to control the quality?
A: We should be checking & testing everyone drill rod before shipment.
Q: Do you agree sample order?
A: Yes, we are welcome your sample order to testing our quality.
Q: Do you have after-sale service and warranty service?
A: Any quality or quantity problem once confirmed, we will be compensate you the same. Any question or problem we will be reply you within 24 hours.

Our Services:

  1. Quality control system.
  2. After-sale service.
  3. Brand new & not used.
  4. Product drawing and design.
  5. 24 hours service.
