Electric Water Leak Detection System For Waterposition / Depth / Flowing Direction

MT-1S Electrical Water Detector designed for depths of 100m

MT-1S Multi-Function Natural Electrical Field detector is a water detector which is specifically designed for depths of 100m.
It monitors the changes of underground electrical resistivity by measuring the intensity of natural electrical field, then analysing the position and depths of underground water.
This instrument solved a major issue, which is freqency choosing and anti-jamming in a natural electrical field.
It uses waterproof shell and touch screen, which is easy of handling and easy to learn.
This instrument was patented, patent number: 201310205318.9,201110454869.X,201320054153.5,201120214308.8,201120567915.2,201320303919.9

ADMT-1S Multi-Function Natural Electrical Field detector is portable, efficiency, easy-handling and accurate analysis. It is auto-measuring which could show data and curves clearly and simple.
Comparing with traditional DC electrical water detector, its speed of measuring was increased more than 8 times, but the instrument weight was decreased 8 times.
In the past 20 years experience, we won a high reputation and were high acclaimed by our customers.

Main applications:

It is mainly used for finding information of underground water, such as the position, depth, flowing direction, water yield etc. It could solve major issues like drinking water, industrial water and agriculture water.
In the past 20 years experience, we won a high reputation and were high acclaimed by our customers.

Technical parameters:
Measuring range: 0-255mv
Detection depth: <150m
Measuring channel: 6 channels
Measuring frequency: 4900,3300,2000,600,300,170HZ
Frequency tolerance: 2%
Resolution: 0.001mV
Repetitive error: ±5% ±3 Bit
A/D switch: 12 Bits 1Msps
Input impedance: ≥10MΩ
Power frequency suppression: ＞60dB
Data storage: 48W
Display: 128 * 64 LCD
Interface: USB2.0
Power source: DC7.4V 5200mAh lithium battery
Power Consumption: 200mA
Temperature: -10℃～+50℃
Humidity: 60%
Dimension: 28×23×12cm
Weight: 2.6KG
